Claralys filters
Claralys filter cartridges are made in France and offer long-lasting quality. Their honeycomb-textured fabric won't fray with use, and captures more impurities than generic filters, even the smallest ones, to ensure you get the very best filtration. Claralys filters are made from spun-bonded polyester, a virtually indestructible material that prevents dirt build-up and encrustation, and maintains its quality even after repeated washing, for extended service life.
CWW50P3
Other part numbers: SC714, 6CH-950, PWW50P3, AKU1810
Diameter: 152 mm
Length: 195 mm
Top: Handle
Bottom: 1½" SAE thread (46-48 mm outside diameter)
CWW35L
Other part numbers: 4CH-935, PWW35L, R9026113
Diameter: 127 mm
Length: 217 mm
Top: handle
Bottom: female-threaded (SAE) hole with an inside diameter of 44 mm
CWW50L
Other part numbers: SC757, 4CH-949, FC-0172, PWW50L
Diameter: 127 mm (5")
Length: 334 mm (13-3/16")
Top: handle
Bottom: female-threaded (SAE) hole with an inside diameter of 44 mm
CRB25
Other part numbers: SC704, C-4326, PRB25, FC-2375
Diameter: 127 mm (4 15/16")
Length: 337 mm (13 5/16")
Top: inside diameter 54 mm (2 ⅛")
Bottom: inside diameter 54 mm (2 ⅛")
Filtration surface area: 25 square feet (106 pleats)
CRB50
Other part numbers: SC706, C-4950, FC-2390, PRB50, AKU1806
Diameter: 127 mm
Length: 337 mm
Top: 54 mm hole
Bottom: 54 mm hole
Filtration surface area: 50 square feet (212 pleats)
CRB35
Other part numbers: C-4335, 40353, PRB35, AKU1608
Diameter: 127 mm (4 15/16")
Length: 235 mm (9Ό")
Top: 54 mm (2⅛") hole
Bottom: 54 mm (2⅛") hole
CRB75
Other part numbers: SC733, C-4975, FC-2395, PRB75
Diameter: 127 mm
Length: 511 mm
Top: 54 mm hole
Bottom: 54 mm hole
CWL25P4
Other part numbers: SC809, PWL25P4-M, AKU1610 / AM00243
Diameter: 143 mm
Length: 174 mm
Top: Handle
Bottom: 1.5" MPT thread (46-47 mm outside diameter)
CMAX50P4
Other part numbers: SC718, 5CH-35, FC-0300, PMAX50P4
Diameter: 146 mm
Length: 203 mm
Top: handle
Bottom: 1.5" MPT thread (46-47 mm outside diameter)
CWW10
Other part numbers: SC750, C-4310, FC-3077, PWW10
Diameter: 108 mm
Length: 102 mm
Top: 52 mm hole
Bottom: 52 mm hole
CWK30
Other part numbers: SC712, C-6430, FC-3915, PWK30
Diameter: 153 mm (6")
Length: 267 mm (10⅞")
Top: 49 mm (1 15/16") hole
Bottom: 49 mm (1 15/16") hole
CPG50P4
Other part numbers: 60508, 6CH-49, FC-0314, PPG50P4
Diameter: 152 mm
Length: 203 mm
Top: handle
Bottom: 1.5" MPT thread (46-47 mm outside diameter)
CCAL100
Other part numbers: SC792, C-4995, FC-2940, PCAL100
Diameter: 125 mm (4 15/16")
Length: 595 mm (23 5/8")
Top: 54 mm (2 ⅛") hole
Bottom: 54 mm (2 ⅛") hole
CCST120 / Coast Spas
Other part numbers: SC769, C-5351, FC-2976, PCST120
Diameter: 140 mm
Length: 770 mm
Top: 54 mm (2 3/16") hole
Bottom: 54 mm (2 3/16") hole
CDSF25-50
Other part numbers: C-4429, FC-3082, DSF25-50
Diameter : 126 mm
Length : 267 mm
Top: 54 mm hole
Bottom: 52 mm hole
Pair of CRB17.5 filters
Other part numbers: SC726, C-4401, FC-2386, PRB17.5SF
Diameter: 125 mm
Length: 117 mm - each filter
Top: 54 mm diameter hole
Bottom: 54 mm diameter hole
The price is for a pair of filters, not a single filter!
CDM30 Oval shaped / Dream Maker Spas
Other part numbers: SC817, PDM30, 461269, 461272
Filter height: 245 mm
Long diameter of the oval: 159 mm
Short diameter of the oval: 132 mm
Inside diameter of the central column: 75 mm
CLBS50
Other part numbers: SC756, C-5345, FC-2970, PLBS50
Diameter: 140 mm (5 5/16")
Length: 260 mm (10 1/8")
Top: 54 mm (2⅛") hole
Bottom: 54 mm (2⅛") hole
CLBS75
Other part numbers: SC777, C-5374, FC-2971, PLBS75
Diameter: 135 mm (5 5/16")
Length: 375 mm (14 3/4")
Top: 54 mm (2⅛") hole
Bottom: 54 mm (2⅛") hole
CAT25P4
Other part numbers: PAT25P4
Diameter: 150 mm
Length: 180 mm
Top: handle
Bottom: 1.5" MPT thread (46-47 mm outside diameter)
CSANT20P3
Other part numbers: SC728, 4CH-925, FC-0126, PSANT20P3
Diameter: 120 mm
Length: 180 mm
Top: handle
Bottom: 1½" SAE thread (46-48 mm outside diameter)
CWK35B
Other part numbers: SC740, FC-3920, PWK35B
Diameter: 160 mm
Length: 360 mm
Top: 49 mm (1-15/16") hole
Bottom: 49 mm (1-15/16") hole
CTL50W-SV-P4
Other part numbers: 6CH-50, FC-0340, PTL50W-SV-P4
Diameter: 150 mm
Length: 330 mm (filter body, without handle and screw thread)
Top: handle
Bottom: 1½" MPT thread (46-47 mm outside diameter)
6 x CWW50P3
Diameter: 152 mm
Length: 195 mm
Top: Handle
Bottom: 1½" SAE thread (46-48 mm outside diameter)
6 x CWW35L
Diameter: 127 mm
Length: 217 mm
Top: handle
Bottom: female-threaded (SAE) hole with an inside diameter of 44 mm
6 x CWW50L
Diameter: 127 mm (5")
Length: 336 mm (13-3/16")
Top: handle
Bottom: female-threaded (SAE) hole with an inside diameter of 44 mm
6 x CRB25
Diameter: 127 mm (4 15/16")
Length: 337 mm (13 5/16")
Top: inside diameter 54 mm (2 ⅛")
Bottom: inside diameter 54 mm (2 ⅛")
Filtration surface area: 25 square feet (106 pleats)
6 x CRB50
Diameter: 727 mm
Length: 338 mm
Top: 54 mm hole
Bottom: 54 mm hole
Filtration surface area: 50 square feet (212 pleats)
6 x CRB35
Diameter: 127 mm (4 15/16")
Length: 235 mm (9Ό")
Top: 54 mm (2⅛") hole
Bottom: 54 mm (2⅛") hole
6 x CWL25P4
Diameter: 143 mm
Length: 174 mm
Top: Handle
Bottom: 1.5" MPT thread (46-47 mm outside diameter)
6 x CMAX50P4
Diameter: 146 mm
Length: 203 mm
Top: handle
Bottom: 1.5" MPT thread (46-47 mm outside diameter)
6 x CWK30
Diameter: 153 mm (6")
Length: 267 mm (10⅞")
Top: 49 mm (1 15/16") hole
Bottom: 49 mm (1 15/16") hole
6 x CPG50P4
Diameter: 152 mm
Length: 203 mm
Top: handle
Bottom: 1.5" MPT thread (46-47 mm outside diameter)
6 x CCAL100
Diameter: 125 mm (4 15/16")
Length: 595 mm (23 5/8")
Top: 54 mm (2 ⅛") hole
Bottom: 54 mm (2 ⅛") hole
6 x Pairs of CRB17.5
Diameter: 125 mm
Length: 117 mm - each filter
Top: 54 mm diameter hole
Bottom: 54 mm diameter hole
The price is for a pair of filters, not a single filter!
CDM30
Filter height: 245 mm
Long diameter of the oval: 159 mm
Short diameter of the oval: 132 mm
Inside diameter of the central column: 75 mm
5 x CLBS75
Diameter: 135 mm (5 5/16")
Length: 375 mm (14 3/4")
Top: 54 mm (2⅛") hole
Bottom: 54 mm (2⅛") hole
